Overview
Get ultra smooth extension for TVs, displays and monitors while still getting a very low profile in home position.
- Up to 9.69" (246.1 mm) extension
- Ultra low-profile 1.88" (47.6 mm) deep in home position
- 10 degrees forward tilt and 5 degrees backward tilt
- 45 degrees of swivel in either direction (dependent on screen size)
- Installs on 16" center studs, single or dual wood stud installation/dual steel stud installation
- Simple cable management
- Integrated lateral shift for repositioning the mount right or left after installation for amazing positioning flixibility.
- Display can be installation in portrait or landscape position. PAC 400 or MAC400 accessory can be used to rotate without removing the screen.
Specification
Dimensions & Measurements
| Depth | 1.9 |
| Height | 11.3 |
| Lateral Shift | 0.75 in (1.9 cm) |
| Overall Dimensions | 11.3" x 18.0" x 1.9" (287 x 457 x 48mm) |
| Shipping Weight | 23.7 lbs (10.8 kg) |
| Typical Screen Size | 32" - 65" (813mm - 1651mm) |
| Wall Stud Compatibility In | 16" (406mm) |
| Weight Capacity | 125 |
| Width | 18 |
Characteristics & Features
| Adjustability |
|
| Application | Wall |
| Color | Black |
| Notes | Depth and Extension do not include interface bracket (adds 0.5 - 1.5") |
| Orientation |
|
| Tilt | +5° / -10° |
| VESA Mounting Pattern | 100 x 100mm - 709 x 431mm |
