| CONDUCTOR PARAMETERS | - |
| Number Of Conductors | 2 |
| AWG Size | 16 |
| Conductor Stranding | 19x29 |
| Conductor Type | Bare Copper |
| Nominal DCR | 4.2 Ohm/1000ft |
| INSULATION PARAMETERS | - |
| Insulation Type | PVC |
| Insulation Thickness | 0.01 in |
| Insulation Color Code | 1. Black 2.Red |
| SHIELDING PARAMETERS | - |
| Shield Type | Aquaseal Water Blocking Tape |
| ELECTRICAL CHARACTERISTICS | - |
| Nominal Capacitance Between Conductors | 34 pF/ft |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Jacket Type | UV Resistant PVC |
| Jacket Thickness | 0.025 in |
| Nominal Cable O.D. | 0.242 in |
| Plenum | No |
| NEC UL Rating | CM, CL3, FPL |
| RoHS Compliant | Yes |
| TIA Test | TIA455-82 Water Penetration Test |
| Pull Tension | 55 lbs |
| Bend Radius | 2.178 in |
| Cable Weight | 29 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - |
| UL Flammability | UL1685 |
| Operating Range | -20 to 60 Deg C |
| UL Voltage Rating | 300 |
