| CONSTRUCTION & DIMENSIONS | - |
| CONDUCTOR PARAMETER | - |
| Number of Conductors | 1 |
| AWG Size | 20 |
| Conductor Stranding | Solid |
| Conductor Type | Bare Copper |
| Nominal DCR | 10.2 Ohm/1000ft |
| INSULATION PARAMETER | - |
| Insulation Type | Foam Polyethylene |
| Insulation Thickness | 0.142 in |
| SHIELDING PARAMETER | - |
| Shield Type | 95% Bare Copper Braid |
| Shield Type 2 | Aquaseal Water Blocking Tape |
| ELECTRICAL CHARACTERISTICS | - |
| Nominal Impedance | 75 Ohm |
| Nom. Cap. Between Conductors | 16.2 pF/ft |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Jacket Type | UV Resistant PVC |
| Nominal Cable O.D. | 0.28 in |
| Plenum | No |
| NEC UL Rating | CM |
| RoHS Compliant | Yes |
| TIA Test | TIA455-82 Water Penetration Test |
| Pull Tension | 70 lbs |
| Bend Radius | 2.8 in |
| Cable Weight | 37 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - |
| Nominal Velocity of Propagation (VP) | 82 % |
| UL Flammability | UL1685 |
| Operating Range | -20 to 60 Deg C |
| UL Voltage Rating | 300 |
| FREQUENCY (MHz) | ATTENUATION (db/100ft) |
| 1 MHz | .29 dB/100ft |
| 10 MHz | .68 dB/100ft |
| 50 MHz | 1.8 dB/100ft |
| 100 MHz | 3 dB/100ft |
| 200 MHz | 3.54 dB/100ft |
| 400 MHz | 4.71 dB/100ft |
| 700 MHz | 6.4 dB/100ft |
| 900 MHz | 7.33 dB/100ft |
| 1000 MHz | 7.8 dB/100ft |
