| CONSTRUCTION & DIMENSIONS | - |
| CONDUCTOR PARAMETER | - |
| Number of Conductors | 2 |
| AWG Size | 8 |
| Conductor Stranding | 65x26 |
| Conductor Type | Bare copper |
| Nominal DCR | 0.7 Ohm/1000ft |
| INSULATION PARAMETER | - |
| Insulation Type | PVC-Nylon |
| Insulation Thickness | 0.038 in |
| Insulation Color Code | 1. Black 2.White |
| SHIELDING PARAMETER | - |
| Shield Type | None |
| ELECTRICAL CHARACTERISTICS | - |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Jacket Type | PVC |
| Jacket Thickness | 0.062 in |
| Nominal Cable O.D. | 0.498 in |
| Plenum | No |
| NEC UL Rating | TC Direct Burial Sunlight Resistant |
| RoHS Compliant | Yes |
| Pull Tension | 410 lbs |
| Bend Radius | 4.482 in |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - | |
| UL Flammability | UL1685 | |
| Operating Range | -25 to 90 Deg C - Dry THHN
|
|
| UL Voltage Rating | 600 |
|
-25 to 75 Deg C - Wet THWN |
