The RCF HDL26-A is an ultra-compact bi-amped two-way active touring system for small and medium-sized events, both indoors and outdoors. Due to the advanced transducer design and the 2000W Class-D amplifier, among the best in its class, it is capable of an extended bottom-end and a pristine sound for a wide range of applications, alone or in RDNet managed line-array configurations. The HDL 35-AS is the ideal flyable bass complement for the HDL 26-A array system.
Features- 133 dB Max SPL
- 2000W Two-Way Amplifier
- Exclusive FiRPHASE technology on-board
- 750 Hz Crossover for best vocal reproduction
- RDNet Networked Management
- 3” Titanium Compression Driver
- 2 x 6” High-Powered Neodymium Woofers
- 4 PATH waveguide
Specifications
ACOUSTICAL- Frequency Response: 55 Hz - 20000 Hz
- Max SPL @ 1m: 133 dB
- Horizontal coverage angle: 100°
- Vertical coverage angle: 10°
- Compression Driver: 1 x 1.5'' neo, 3.0'' v.c
- Woofer: 2 x 6.0'' neo, 2.0'' v.c
- Input signal: bal/unbal
- Input connectors: XLR, RDNet Ethercon
- Output connectors: XLR, RDNet Ethercon
- Input sensitivity: +4 dBu
- Crossover Frequencies: 750
- Protections: Thermal, RMS
- Limiter: Soft Limiter
- Controls: Preset, RDNet bypass
- RDNet: Onboard
- Total Power: 2000 W Peak, 1000 W RMS
- High frequencies: 600 W Peak, 300 W RMS
- Low frequencies: 1400 W Peak, 700 W RMS
- Cooling: Convection
- Connections: Powercon IN/OUT
- Safety agency: CE compliant
- Cabinet/Case Material: PP Composite
- Hardware: Array fittings
- Handles: 2 Back
- Grille: Steel
- Color: Black, White
- Height: 237 mm / 9.33 inches
- Width: 470 mm / 18.5 inches
- Depth: 377 mm / 14.84 inches
- Weight: 13.5 kg / 29.76 lbs
- Package Height: 260 mm / 10.24 inches
- Package Width: 550 mm / 21.65 inches
- Package Depth: 425 mm / 16.73 inches
- Package Weight: 14.9 kg / 32.85 lbs
