Features
- Distribution of 24 Vdc Power
- Soft-Start from Switching Supply
- Distribution of dc Power
- Up to 5 Power Distribution Points
- Voltage Presence Indication
- Reverse Voltage Protection
Specifications
| Input/Output Voltage | 24 Vdc @ 2 A (Intended for use with current limited switching supply) |
| Number of Outputs (5) | Total load current must not exceed 2 A |
| Indicators (2) | POWER LED, FAULT LED indicating output inactive due to excessive load current |
| Ambient Operating Environment | 0° C to 50° C |
| Package Type | Cardboard Box |
| Package Dimensions | 2 x 2 x 4 in. |
| Shipping Weight | 0.21 lbs. |
| WEEE weight | 0.16 lbs. |
| Tariff code | 8518.29.0000 |
