Features
- Studio Quality Bifilar Audio Transformer
- Connectorized Audio Format Conversion
- Galvanic Isolation with the Convenience of RDL TXs
- Gold Contacts on Input and Output
- Unbalanced to Balanced Conversion
- Unity Gain
- Frequency Response: 20 Hz to 20 kHz (+/- 0.1 dB)
- THD: < 0.06% (50 Hz to 20 kHz, -10 dBV input)
0.0015% (Typ. 1 kHz, -10 dBV input) - Input: -10 dBV (+22 dBu max.), 10 kΩ Phono jack
- Insertion Loss: 0.25 dB (20 Ω source; 10 kΩ load)
- Insertion Loss: 0.25 dB (20 Ω source; 10 kΩ load)
Specifications
| Ambient Operating Environment | 0° C to 55° C |
| Package Type | Cardboard Box |
| Package Dimensions | 2 x 2 x 4 in. |
| Shipping Weight | 0.62 lbs. |
| WEEE weight | 0.565 lbs. |
| Tariff code | 8518.29.0000 |
