Overview:
The Vivitek DU8053Z-BK is a professional large-venue dual-laser projector designed for auditoriums, houses of worship, museums, higher education, rental and staging, and commercial AV installations. Delivering up to 14,000 lumens of brightness and featuring a sealed optical engine, the projector offers built-in edge blending, geometric correction, image warping, and lens position memory for flexible installation. With support for optional motorized lenses, HDBaseT connectivity, 360° projection, portrait orientation, and 24/7 operation, the DU8053Z-BK is engineered for demanding professional environments.
Features:
14,000-lumen brightness
Dual-laser light source
Built-in edge blending
Built-in image warping
Built-in geometric correction
Lens positioning memory
HDBaseT connectivity
3G-SDI support
360-degree projection capability
Portrait mode installation
24/7 operation support
Optional motorized lenses
Constant brightness technology
Auto color correction support
Network management and control
Specs:
| Product Type | Large Venue Dual-Laser Projector |
| Projection System | 1-Chip DLP 0.8" |
| Native Resolution | WUXGA (1920 x 1200) |
| Maximum Resolution | 3840 x 2160 (4K UHD) |
| Brightness | 14,000 Lumens |
| Brightness Uniformity | 90% |
| Contrast Ratio | 3,000,000:1 |
| Light Source | Dual Laser Technology |
| Light Source Life | 20,000 Hours (Normal) / 30,000 Hours (Eco) |
| Aspect Ratio | 16:10 |
| Lens Type | Optional Motorized Interchangeable Lenses |
| Lens Shift (Horizontal) | +60% to -60% |
| Lens Shift (Vertical) | +20% to -20% |
| HDMI Inputs | 2 x HDMI 2.0 |
| DisplayPort Inputs | 2 x DisplayPort |
| DVI-D Input | 1 |
| 3G-SDI | Input x1 / Output x1 |
| HDBaseT | Yes |
| LAN | RJ45 |
| Operation | 24/7 Continuous |
| Projection Orientation | 360° and Portrait Mode |
| Power Requirement | 100-240V AC, 50/60Hz |
| Power Consumption | 860W@100V / 830W@240V |
| Product Weight | 64.8 lb |
| Product Dimensions | 23.3 x 19.7 x 8.6 in |
