Overview
The MT100 AI Audio-Visual Tracking Box is an intelligent control hub designed to integrate audio and video systems for modern conference rooms. It bridges AISPEECH's ceiling microphone arrays with multiple cameras to deliver a seamless hybrid meeting experience.
MT100 leverages advanced AI algorithms to provide precise speaker tracking and intelligent camera control. By combining audio positioning data from AISPEECH ceiling microphones with visual recognition, it automatically frames active speakers and switches between camera views. The compact design integrates easily into existing AV systems, supporting both local and remote collaboration. With support for up to 6 cameras and unlimited ceiling microphones, MT100 scales to fit various room sizes and configurations.
Features
Advanced AI Technology for Intelligent Audio-Visual Integration
Multiple Camera Support
- Connect up to 6 cameras simultaneously with intelligent switching and tracking capabilities. Supports various camera models including PTZ and fixed cameras for comprehensive room coverage.
AI-Powered Tracking
- Advanced AI algorithms enable precise speaker tracking and auto-framing. Seamlessly follows active speakers with smooth transitions and intelligent zone detection for professional video conferencing.
Audio-Visual Synchronization
- Perfect synchronization between AISPEECH ceiling microphones and connected cameras. Voice positioning technology ensures the camera tracks the active speaker with high accuracy.
Flexible Integration
- Works seamlessly with AISPEECH's MC08, MC10, and other ceiling microphone systems. Easy integration with existing AV infrastructure through standard protocols.
4K Output Support
- Supports up to 4K resolution at 30fps output for crystal-clear video quality. Multiple output interfaces including HDMI and USB for flexible connectivity.
Intelligent Scene Control
- Automated scene switching and preset management for different meeting scenarios. Supports manual override and custom configurations for enhanced control.
Specifications
Basic
- Product Model: AIVIS-MT100
- Product Color: Black
- Dimensions: 220mm × 150mm × 45mm
- Net Weight: ≈1.2 kg
- Power Supply: DC 12V
- Power Consumption: <25W
- Operating Temperature: 0°C ~ 40°C
- Storage Temperature: -20°C ~ +60°C
Camera Support
- Maximum Connected Cameras: 6
- Camera Type Support: PTZ, Fixed, USB
- Video Resolution: Up to 4K @ 30fps
- Video Output: HDMI, USB 3.0
- Camera Control Protocol: VISCA, Pelco-D/P
Audio Integration
- Microphone Compatibility: AISPEECH MC08, MC10, MCS06, MA600D
- Maximum Microphones: Unlimited (via Dante network)
- Audio Network: Dante
- Voice Positioning: AI-powered speaker localization
- Tracking Accuracy: ±5°
Tracking Features
- Tracking Mode: Auto, Manual, Preset
- Tracking Zones: Up to 16 configurable zones
- Tracking Speed: Adjustable (Smooth/Fast)
- Face Detection: Supported
- Multiple Speaker Detection: Supported
Interfaces
- Video Input: 6 × HDMI 1.4
- Video Output: 2 × HDMI 1.4, 1 × USB 3.0
- Network Port: 2 × RJ-45 Gigabit Ethernet
- Audio Interface: Dante (via network)
- Control Interface: RS-232, RS-485
- USB: 1 × USB 3.0 Type-B (UVC output)
Control & Management
- Control Method: Web interface, RS-232/485, API
- Preset Positions: Up to 64 per camera
- Scene Presets: Up to 32
- Remote Management: Supported
- Firmware Update: Web-based OTA
