Overview
Step up to the new standard in creative live audio production with Allen & Heath's C-class mix racks featuring dLive V2.0 and and the new RackUltra FX suite powered by the RackUltra FX card. With powerful new reverbs like Spaces Reverb Designer and Plate Reverb Designer, you can recreate physical spaces and capture characterful plate reverb sounds with unprecedented realism. Take control of vocal processing with Vocal Tuner, Vocal Gridder, and Vocal Shifter, offering studio-quality pitch correction and vocal manipulation right from your console. Enhance your mix with three harmonizers, including Quad Voice Harmonizer and MIDI Harmonizer, and add depth with the new distortion effects: Saturation and Amp+Cab Distortion. Plus, with the RackUltra FX Card, you get 8 powerful FX engines without sacrificing any of your system's resources. And that's not all – dLive V2.0 also brings powerful new workflow improvements, from a revamped Cue List system to the versatile Actions feature and an extended Channel Library. Elevate your live mixing experience with dLive V2.0.
If you don't need more analog I/O but want to add DSP and expand your digital capabilities then the DM0 RUFX is designed for you. Built around the Allen & Heath XCVI processing core with a 96kHz signal path and variable bit depth, the system possesses an unmatched noise floor that results in virtually infinite dynamic range. Expand your digital I/O with 2 DX ports, and easily configure your setup with plug-and-play connectivity and ultra-low transport latency. Take control with dLive Director software on your PC or Mac, the dLive MixPad app for iPad, or A&H's small-format IP Controllers, offering the flexibility to mix anywhere in the venue. Plus all S-calss MixRacks feature redundant Surface Link and DX Links for added peace of mind because the show must go on! All items sold separately. Create the mix in your head with the dLive DM0 RUFX!
Features
- XCVI 160×64 FPGA processing core
- 96kHz XCVI FPGA processing core with 96-bit accumulator
- Virtual soundcheck, ultra-low latency and noise performance
- Virtually infinite mix headroom thanks to 96-bit accumulator
- Class-leading, ultra-low latency: 0.7ms
- 128 Input Channels with full processing
- 64 Mix Outputs with full processing
- Configurable 64 bus architecture (Group, FX, Aux, Matrix, Mains)
- LR, LCR, and up to 5.1 mains mode
- Multiple PFLs
- 16 RackExtra FX with dedicated stereo returns
- Automatic Mic Mixer (AMM) up to 4 zones, 64 ch
- Deep processing - powerful embeded plugins including GEQ and compressor modelling
- Built-in signal generator, RTA and spectrogram
- Connection hub
- Dual redundant gigaACE link to Surface
- DX redundant DX links for I/O expansion
- DX ports and up to 3 DX32 mains mode
- Dedicated ME-1 48kHz port
- 2 Network ports
- Wordclock BNC I/O
- Dual redundant power supply
- Flush front panel with ultra-quiet fan
- Reversible rack ears design
Specifications
System
- dBFS Alignment: +18 dBu = 0 dBFS
- Meter Calibration: 0 dB meter = -18 dBFS
- Meter Peak Indication: -3 dBFS
- Sampling Rate: 96kHz ±20 PPM
- ADC: 24-bit Delta-Sigma
- DAC: 24-bit Delta-Sigma
- Latency:
- +5 samples, Surface to MixRack (GigaACE hop)
- +8 samples, DX32 to MixRack (DX hop)
Operating Conditions and Power
- Operating Temperature Range: 0°C to 35°C (32°F to 95°F)
- Mains Power: 100–240V AC, 47–63Hz, 90W maximum per PSU
Dimensions and Weights
- DM0
- Dimensions (Width × Depth × Height): 482.6 × 355 × 176 mm (19" × 14" × 6.9")
- Weight: 12 kg (26.5 lbs)
- DM0 - Boxed
- Dimensions (Width × Depth × Height): 600 × 480 × 330 mm (23.7" × 19" × 13")
- Weight: 15 kg (33 lbs)
