Overview:
The Allen & Heath dLive DM32 RUFX is an S-Class MixRack that serves as the processing core of a dLive mixing system. Featuring 32 mic/line inputs, 16 line outputs, redundant Surface and DX links, three I/O ports, Allen & Heath's XCVI 96kHz FPGA engine, and a pre-installed RackUltra FX card, the DM32 RUFX delivers 128 input channels, 64 mix outputs, configurable 64-bus architecture, and ultra-low 0.7ms latency for touring, broadcast, installation, and premium live sound applications.
Features:
XCVI 96kHz FPGA processing engine
32 recallable mic preamps
16 analog outputs
RackUltra FX card pre-installed
128 input channels
64 mix outputs
64-bus architecture
0.7 ms system latency
Dual redundant Surface links
Dual redundant DX links
96-bit accumulator processing
Active PAD microphone preamps
Supports up to 4 dLive surfaces
Optional redundant power supply
Specs:
Product Type: Digital MixRack / Stage Box
Series: dLive S-Class
Mic/Line Inputs: 32
Line Outputs: 16
Mix Engine: XCVI Core
Input Channels: 128
Mix Outputs: 64
Bus Architecture: 64-Bus Configurable
Sampling Rate: 96 kHz
Latency: 0.7 ms
I/O Ports: 3 x 128-Channel I/O Ports
Surface Links: Dual Redundant gigaACE
DX Expansion Ports: 2 Redundant DX Links
Network Ports: 2
Word Clock: NC I/O
RackUltra FX Card: Included
Dedicated ME Port: 48 kHz ME Personal Mixing Port
Power Supply: Hot-Swappable PSU
Redundant PSU Support: Yes (Optional)
