Overview
A complete makeover of X-310, we proudly present you F-1 Fazer equip with new technology and features from the F-Series family.
The air pump system enhances and smooth the mixture of fog liquid and air to produce fine, dry fog with minimal fluid consumption. Also, enable the machine with a self-cleaning function to extend the lifespan of heater elements. Smart auto-sensing frequency feature allows the machine to self adjust to the local frequency without the hassle to change any setting.
‧3 DMX Control Mode
– Fog volume with fan at 100%
– Fog and Fan volume control
– Fog and Fan sync mode
‧Larger tube diameter
‧Built-in air pump with self-cleaning function
‧The stability in all details while the maturity reaches perfection
‧Highest fog quality: dry and pure
SPECIFICATION
| Rated voltage |
US model : AC 100-120V, 50/60Hz 6.8A EU model : AC 220-240V, 50/60Hz 3.5A |
| Rated power | 800W |
| Warm-up time | 4.5 minutes (approx) |
| Fluid consumption | 8.5 ml/min |
| Fluid tank capacity | 2.4 Liters (0.63 gallon) |
| Compatible fluid |
Antari FLG Heavy Fog Fluid Antari FLH Super Fog Fluid Antari FLZ Long Hang Time Fog Fluid (Only applicable to machines manufactured after May 2020) |
| Operating time | 4.5 hrs at max. output |
| Ambient temp/ range | 0°C – 40°C (32°F – 104°F) |
| Control |
Manual, Timer, DMX 512 Wireless (Optional)、Wireless DMX (Optional) |
| DMX channels | 2 channels |
| Connection |
Neutrik Powercon (Power) XLR 3-pin and 5-pin (DMX) |
| Optional accessories |
TIMO-W-DMX-PCBR Wireless DMX、WTR-10 Wireless Remote、 TIMO-WTR-40 Wireless DMX and Remote |
| Dimension |
L 618 W 275 H 327 mm (L 24.33 W 10.83 H 12.87 inch) |
| Weight | 14.1 kg (31.09 lbs) |
