Overview:
Building upon the success of the original Cloud 9, the CHAUVET PROFESSIONAL Cloud 9X IP is a low-lying fog machine that creates thick, cloud-like effects with high, sustained output well suited for large-scale stages, theaters, live performances, and theme parks. This updated version features an upgraded housing that is not only inherently corrosion resistant, but also significantly lighter. It is also stackable (up to 3 tall), making for easy transportation by truck, and features a removable rear cover for storing accessories, keeping everything self-contained in the unit.
The Cloud 9X IP boasts a super-fast five-minute heat up time and requires no CO2 or dry ice for operation. The innovative design utilizes an ultrasonic agitator that combines distilled water and standard fog fluid to produce low-lying fog effects. The unit can operate for two hours at 100% and provides a whopping 15,000 cfm with coverage up to 3240 ft². An integrated water drain system makes for fast and easy cleanup. Operate the unit via the onboard control panel or via two-channel DMX (fan speed / fog output). The Cloud 9 ships with a power cord and 11' directional hose with clamp.
Features:
Compact, professional fogger gives high-impact, low-lying fog effect on stage or in ballrooms
Suitable for temporary outdoor/wet use
Continuous operation produces fog to cover 3230 ft2 area
Ultrasonic agitators combine water with fog to produce low-lying fog effect
Ships in integrated, rugged flight case with locking casters suitable for rental/touring applications with removable cover for rear panel
Control via onboard full color display, wireless (RF) handheld remote, or DMX
Integrated water drainage system makes cleanup fast and easy
Use the low-lying fog fluid (LLG) to produce the CO² effect, which lasts for several minutes before dissipating
Use without dry ice or CO2, so no special licensing/training required
USB-C slot for software uploads
Specs:
Item Type
1x Fog Machine
Remote Control
Wireless Remote (Receiver Built-In & Remote Included)
Tank Capacity
Fog Fluid Tank:
0.8 gal / 3 L
Water Tank:
7.7 gal / 29.1 L
Warm-Up Time
5 Minutes
Power Source
AC Power (Cable Included - 5' / 1.5 m)
Power I/O
1x Powerkon IP65 Input
Other I/O
1x XLR 3-Pin DMX Input
1x XLR 3-Pin DMX Output
1x XLR 5-Pin DMX Input
1x XLR 5-Pin DMX Output
1x USB-C Firmware Input
tem Type
1x Fog Machine
Color
Black
Built-In Light
No
Remote Control
Wireless Remote (Receiver Built-In & Remote Included)
Output Power
81 ft³ / 2.29 m³ per Minute
Tank Capacity
Fog Fluid Tank:
0.8 gal / 3 L
Water Tank:
7.7 gal / 29.1 L
Warm-Up Time
5 Minutes
Fluid Consumption
Fog Fluid: 0.9 fl oz / 27.8 mL per Minute
Duty Cycle
2-Hour Runtime at Maximum Output
Power & I/O
Power Source
AC Power (Cable Included - 5' / 1.5 m)
Power I/O
1x Powerkon IP65 Input
Other I/O
1x XLR 3-Pin DMX Input
1x XLR 3-Pin DMX Output
1x XLR 5-Pin DMX Input
1x XLR 5-Pin DMX Output
1x USB-C Firmware Input
Input Power
120 VAC, 60 Hz
DMX Channel Modes
1 Mode(s):
3-Channel
Power Consumption
1960 W
General
Certifications
CE, RoHS, UKCA
Operating Conditions
-4 to 113°F / -20 to 45°C
Dimensions
37.72 x 19.22 x 17.36" / 95.81 x 48.82 x 44.09 cm
4.8" / 12.1 cm (Output Nozzle Outer Diameter)
6' / 1.8 m (Output Hose)
11' / 3.4 m (Hose Length Fully Extended)
Weight
76.6 lb / 34.7 kg
Packaging Info
Package Weight
103.62 lb
Box Dimensions (LxWxH)
39.25 x 21.5 x 20.25"
