Overview
Flexibility meets form and function with the Kontour™K3 series of elegantly designed static multi-monitor array mounts from Chief.
K3 products provide an aesthetic, stable solution for use in a variety of multi-monitor applications: call centers, control rooms, financial services, gaming, health care, IT, security desks, and others.
Most K3 series configurations are available as free standing or grommet/bolt through mounts. The KRA500 Desk Clamp accessory is also available for most K3 series array mounts.
- Flexible multi-monitor array mounts available in configurations from dual up to six displays
- Products ship largely pre-assembled for fast installation
- Tool-free integrated cable management
- Independent height, pan, & tilt adjustment of each display for flexible monitor positioning
- Free-standing or grommet mounting styles, with optional desk clamp accessory
- Streamlined modern aesthetic
- Majority of Kontour™ K3 products are TAA-compliant
Specification
Dimensions & Measurements
| Depth | 7.03 in (17.9 cm) |
| Height | 20.87 in (53 cm) |
| Overall Dimensions | 20.87" x 40.17" x 7.03" (530mm x 102mm x 178.5mm) |
| Shipping Weight | 25.72 lbs (11.7 kg) |
| TV Width Range | 2x1: 51.2" (1301 mm) max width; 3x1: 25.6" (650 mm) max width |
| Typical Screen Size | 2x1 Up to 30" (762 mm) diagonal, 3x1 Up to 27" (686 mm) diagonal |
| Weight Capacity | 15 lbs (6.8 kg) |
| Width | 40.17 in (102 cm) |
Characteristics & Features
| Adjustability |
|
| Application | Edge Clamp |
| Array Configuration | 3X1 |
| Color | Silver |
| Desktop Thickness Range | 0.5" - 5" (13mm - 127mm) |
| Grommet Hole Size Range | 0.38" - 3.5" (10mm - 89mm) |
| Mounting Method | Desk Clamp |
| Notes | Weight capacity is per monitor |
| Number of Displays | 2 or 3 |
| Orientation |
|
| Post-Installation Leveling Roll | Yes |
| Solution Type | Universal |
| Special Features | Multi-Display |
| Tilt | Heads on rails: 12°; Head on column: 10° |
| VESA Mounting Pattern | 75 x 75mm, 100 x 100mm |
