Overview
View large flat panel displays from any angle.
- See PNRUB, PNRUS, PNR2000B and PNR2000S (PNR2000 mounts require PSB custom or universal interfaces purchased separately) still available.
- Centris Fingertip Tilt allows you to select the perfect tension for your screens center of gravity
- Post-installation height adjustment up to 1 (25 mm) for ultimate flexibility
- Q-Latch Mounting System secures flat panel to mount with a latching flag
- Easy connect/disconnect without tools
- Extends up to 25 (635 mm) for viewing from any angle
- CableTrac System provides channeled cable management for easy cable routing
- Screen can be installed in portrait or landscape orientation (PAC400 accessory can be used to rotate without removing the screen)
Specification
Dimensions & Measurements
| Depth | 3.3 |
| Height | 21.2 |
| Lateral Shift | 9 in (228.6 mm) |
| Minimum Depth | 3.25 in (8.3 cm) |
| Shipping Weight | 52-52 lbs (23.59-23.59 kg) |
| Typical Screen Size | 42"- 86" (1067mm - 2184mm) |
| Weight Capacity | 200 |
| Width | 27.1 |
Characteristics & Features
| Adjustability | Extension, Swivel, Tilt, Micro-Adjustable, Height Adjustable, Lateral Shift |
| Application | Wall |
| Color | Black |
| Notes | Depth and Extension do not include interface bracket (adds 0.5 - 1.5") |
| Orientation |
|
| Post-Installation Leveling Roll | Yes |
| Solution Type | Custom |
| Tilt | + 5° / - 15° |
| VESA Mounting Pattern | 200 x 200mm - 862 x 517mm |
