Overview
- High quality transducers for best-in-class performace
- Lightweight and durable resonant free enclosure
- EAW Focusing for unmatched clarity and accuracy
- Linear Conical waveguide optimized for pole mount and monitor applications
The lightweight and durable enclosure has been meticulously designed to eliminate any enclosure resonance and houses on-board bi-amplified electronics (1500W) featuring signature EAW DSP including Focusing and DynO. Our Resolution software platform is a powerful and easy-to-use simulation software that accurately predicts the performance of one or multiple LA Series enclosures within a venue or performance.
Applications
- Live Production/Regional Rental Houses
- Live Music and Dance Clubs
- Corporate AV Houses
- Houses of Worship
- Dry Hire
Specifications
- Frequency Response: 47 Hz to 20 kHz
- Max SPL: 137dB
- Operating Mode: Bi-Amp LF, HF
- Subsystem
- LF Transducer, 12in Cone, 2.5in Voice Coil,Vented
- HF Transducer, Loading, 1.4in Exit, 3in voice coil neodymium compression driver, Linear Conical Waveguide
- Nominal Beamwidth: 90° Conical, Vertically Asymmetric (+40, -50)
- Power Handling: 1500W
- Connections
- Neutrik PowerCON®
- Input Type: Electronically Balanced XLR / TRS
- Loop Type: Electronically Balanced XLR
- Dimensions
- Height: 25.2in (640mm)
- Width: 15in (380mm)
- Depth:14.4in (365mm)
- Weight: 40lb (18kg)
