TORUS T820 is a passive, two-way loudspeaker engineered for small to medium-scale applications which do not call for the longer throw capabilities of a line array. With exceptional ease-of-use, scalability and deployment flexibility, it is primarily used as an array element in vertical constant curvature arrays as well as being used singly as a point-source loudspeaker. In venues with short throws, yet high ceilings like some theatres, a horizontal centre cluster may also be a practical solution.
Features
- Two-way, constant curvature array element
- Compact enclosure with high output capability
- 1 x 8” (200mm) LF driver plus 2 x 1.4” (35mm)/1” (25mm) exit HF drivers
- 100° horizontal dispersion x 20° vertical dispersion
- Easy-to-use integral rigging for quick set-up
- Integral fittings to facilitate pole-mounting
- Optimised coverage via DISPLAY 3
- Powered by iKON amplifiers
Applications
- Short to medium-throw live sound
- Theatre sound
- Fixed installations
- Fills, centre clusters and delays
- Portable DJ and corporate events
Specifications
| PRODUCT NAME | TORUS 8: T820 |
| TYPE | Passive 2-way, 8” Constant Curvature 20° enclosure |
| FREQUENCY RESPONSE (with iKON settings) | 70Hz – 18kHz ± 3dB, -10dB @ 56Hz |
| DRIVERS | LF: 8” with 2” Voice coil, Neodymium HF: 2 x 1” exit, 1.4” Voice coil, HT Polymer dome neodymium compression driver |
| SENSITIVITY | (2.83V 1m free-field) 97dB |
| NOMINAL IMPEDANCE | 8 ohms |
| RATED POWER | AES 200W, PEAK 800W |
| MAXIMUM SPL (SYSTEM) | 124dB continuous, 130dB peak* |
| DISPERSION | 100° horizontal, 20° vertical |
| PIN CONNECTIONS (INPUT) | 1+/- or 2+/- |
| PIN CONNECTIONS (LINK) | 1+/- and 2+/- |
| DIMENSIONS | (W) 500mm, (H) 257mm, (D) 320mm (W) 19.69ins, (H) 10.12ins, (D) 12.60ins |
| WEIGHT | 14kg (31 lbs) |
| *Martin Audio continues to specify a crest factor of 2 with 6dB between peak and continuous which best mirrors real-world performance. Simply add a further 6dB for comparison with manufacturers quoting a crest factor of 4 ie. 12dB between continuous and peak. |
