Overview:
The MIDAS HUB4 PRO is a 96 kHz monitor system hub designed for personal monitoring, stage-box expansion, and AES50 audio networking. It provides Power over Ethernet (PoE) for up to four DP48 personal mixers or compatible stage boxes, offers 16 balanced analog outputs for IEM systems, and supports StageCONNECT, AES50, and DL8 stage box integration.
Features:
PoE support for 4 DP48 mixers
AES50 IN and THRU networking
16 balanced analog outputs
8 stereo IEM mixes
StageCONNECT integration
Support for 4 DL8 stage boxes
Channel-name distribution from HD96 and M32 consoles
DP48 remote control forwarding
Talkback routing support
AES50 upstream monitoring
Neutrik etherCON network ports
1U rackmount chassis
Global power supply
Specs:
Product Type: Monitor System Hub
Sample Rate: 96 kHz
PoE Ports: 4
Personal Mixer Support: Up to 4 DP48 Mixers
AES50 Connectivity: AES50 IN, AES50 THRU
Audio Capacity: 48 Bidirectional Channels @ 48/44.1 kHz, 2 x 24 Channels @ 96 kHz
Analog Outputs: 16 Balanced Outputs
Stereo Mix Outputs: 8 Stereo Mixes
StageCONNECT: 32 Channels, 24-Bit PCM Audio, 44.1 / 48 kHz
Stage Box Support: Up to 4 MIDAS DL8 Stage Boxes
Rack Size: 1U
Maximum AES50 Cable Length: 250 ft
Power Supply: Auto-Ranging Universal, Switch-Mode
Package Weight: 10.8 lb
Box Dimensions (LxWxH) 22.4 x 14.6 x 3.8"
