Overview
Specify an SRSR for easy rear access to equipment connections in millwork, cabinets and flush in-wall installations. Available with a 19” or 23” useable depth, the SRSR system extends and rotates 90º in either direction, making it ideal for smaller systems.
- Removable rack frame allows in-shop integration and on-site installation of equipment
- Locks in the extended position for simplified equipment integration
- Rotating equipment bay locks in place at 0º, 60º and 90º for easy installation and servicing
- Self-centering mounting base makes it simple to align system within cabinet opening
- Rear cable support works in conjunction with rear rackrail for effective cable management
- Standard front and rear 10-32 threaded rackrail with marked spaces
Specification
Dimensions & Measurements
| Depth | 23.14 |
| Height | 50.25 |
| Primary Package Weight | 57.6 |
| Rack Units | 27 RU |
| Usable Depth | 21.25 |
| Usable Height | 47.25 |
| Weight Capacity | 200 |
| Width | 19.13 |
Characteristics & Features
| Federal Ops Country of Origin | USA |
| Finish | Flat Black Powder Coat |
| Rack Rail Type | 10-32 |
| Rack Type | In-Cabinet |
