Overview
Software value (2 of 2) of the CORE 8 FLEX bundle - cannot be ordered separately
This represents the logical network capacity, virtual DSP deployment engines, Acoustic Echo Cancellation layers, and scalable peripheral licensing running on the Q-SYS OS platform.
Features (SW)
- 64 x 64 networked audio channels (Q-LAN / AES67)
- 8x AEC processors
- Up to 32 x 32 Dante audio channels (8 x 8 included)
- Full-featured Q-SYS Control engine
- Up to 2x VoIP instances
Specifications (SW)
-
Channel Capacity:
- Total network I/O channels: 64 x 64
- Total network I/O streams: 32 x 32
- Dante channels: 8 x 8 (included); licensable up to 32 x 32 with Software-based Dante feature license
- AEC processors: 8
- VoIP instances: 2
- Audio recording / playback: 4 ch recording / 16 ch playback (expandable to 32 ch with optional license)
- Q-SYS NM-T1 capacity: 3 (base capacity); 6 (with Capacity Scaling License)
- Network peripherals: up to 32
-
Platform Licensing & Functionality:
- Control Engine: Pre-installed Q-SYS Control platform including full Scripting Engine and UCI deployment capabilities
- USB Audio Processing: Firmware-driven logic handling 8 x 8 audio bridging channels and native USB HID routing over external connections
