Overview
The Q-SYS PL-DC24 is a compact, two-way passive point source loudspeaker with directivity control that delivers premium sound for a broad range of venue types in entertainment, hospitality, corporate and higher ed applications. This dual-4-inch model offers a fixed 110° x 50° horn, making it ideal for stage fills, delays, or filling in lost coverage when placed under balconies.
Features
- Dual-4-inch LF transducers + HF compression driver in a bass-reflex enclosure
- Weatherized (IP54) wooden enclosure for indoor and protected outdoor environments
- Fixed horn with 110° (horizontal) x 50° (vertical) coverage
- Pairing with Q-SYS CX-Q 4ch network amplifiers enables custom voicings and filter sets for quicker deployment and better sonic performance
- Several mounting options available for a variety of spaces and venue requirements
Specifications
- LF transducer: 2x 4 in (102 mm), 1.3 in (33 mm) voice coil, neodymium
- HF transducer: Compression driver, 1 in (25 mm) voice coil
- Enclosure configuration: Two-way, passive point source loudspeaker in bass reflex enclosure
- Coverage: 110° x 50° (horizontal x vertical)
- System sensitivity: 97.3 dB @ 1 W/1 m
- Max SPL (continuous): 114 dB
- Enclosure material: Exterior plywood
- Enclosure color: Black (RAL 9011)
- Weatherization: IP54 with treated plywood, stainless screws, UV/corrosion-treated grille, hydrophobic stainless steel mesh, polyurea paint, IP65 sealed input cup with gland
- Recommended amplifiers: Q-SYS CX-Q 8K4 (up to 4 per channel), CX-Q 4K4 (up to 3 per channel), CX-Q 2K4 (up to 2 per channel)
