Overview
The Q-SYS PL-DC26 is a two-way, passive point source loudspeaker with directivity control that delivers premium sound for a broad range of venue types in entertainment, hospitality, corporate and higher ed applications. This dual-6-inch model offers a reconfigurable and rotatable horn, enabling symmetrical or asymmetrical coverage for better control over where sound needs to be heard. Thus, the PL-DC26 offers the flexibility and adaptability to be deployed as stage fills, delays, or filling in lost coverage when placed under balconies.
Features
- Dual-6-inch LF transducers + HF compression driver in a bass-reflex enclosure
- Weatherized (IP54) wooden enclosure for indoor and protected outdoor environments
- Includes reconfigurable and rotatable half-horn assemblies for better control over sound coverage
- Pairing with Q-SYS CX-Q 4ch network amplifiers enables custom voicings and filter sets for quicker deployment and better sonic performance
- Several mounting options available for a variety of spaces and venue requirements
Specifications
- LF transducer: 2x 6 in (170 mm), 1.7 in (44 mm) voice coil, neodymium
- HF transducer: Compression driver, 1.75 in (44 mm) voice coil
- Enclosure configuration: Two-way, passive point source loudspeaker in bass reflex enclosure
- Coverage (horizontal x vertical): Symmetrical 120° x 50°, 90° x 50°; Asymmetrical 105° x 50° (reconfigurable half horn assemblies included)
- System sensitivity: 102.2 dB @ 1 W/1 m
- Max SPL (continuous): 121 dB
- Enclosure material: Exterior plywood
- Enclosure color: Black (RAL 9011)
- Weatherization: IP54 with treated plywood, stainless screws, UV/corrosion-treated grille, hydrophobic stainless steel mesh, polyurea paint, IP65 sealed input cup with gland
- Recommended amplifiers: Q-SYS CX-Q 8K4 (up to 4 per channel), CX-Q 4K4 (up to 2 per channel), CX-Q 2K4 (up to 1 per channel)
