Overview:
Designed to deliver stellar audio performance and adaptability for intensive audio applications, the RCF ART 810-A is a portable, two-way active loudspeaker built for DJs, musicians, and installers who want professional sound, robust performance, and everyday versatility in a sleek, modern form factor. A 2-channel 1400W amplifier powers the 1.75” compression driver and 10” woofer, which works with RCF’s constant-directivity True Resistive Waveguide to deliver consistent 100 x 60° coverage, clear reproduction, and up to 129 dB SPL with low distortion.
The lightweight yet rugged cabinet uses a special polypropylene composite with internal M-brace reinforcement for improved stability and reduced resonance, making ART 810-A fast to deploy, easy to handle, and ready for portable systems or secure installation on a pole, wall, truss, or flown setup via multiple rigging points.
Benefits
129 dB max SPL
1400W Class-D bi-amplification
100 x 60°, wide-dispersion True Resistive Waveguide
1.75” compression driver
10” woofer
FiRPHASE
RCF speakers are designed using a proprietary and advanced digital FiR technology, conceived to deliver transparent sound, absolute clarity, and perfect imaging to the listener. The special FiRPHASE filters allow for coherent distribution of sound for all listeners without phase distortions, ensuring minimum latencies in the system.
XBOOST Low-Frequency Enhancer
XBOOST adds extra depth and impact to the low-frequency response when more bass presence is needed. It can be activated directly from the rear panel, giving users a fast way to adapt the speaker to the performance, the room, or the listening level. For setups without a subwoofer, XBOOST helps create a fuller sound while keeping the overall response controlled and balanced.
True Resistive Waveguide
The integration of waveguide geometry, vented port placement, and FiRPHASE technology enables the speaker to function as a single, coherent source. The True Resistive Waveguide mimics a resonance-free load, reducing high-frequency distortion compared to traditional horn designs. Engineered for consistent performance, the waveguide delivers constant directivity across the listening area, improving coverage and stereo imaging.
Reinforced Composit Enclosure
ART 8 uses a reinforced modern composite enclosure engineered for strength, acoustic stability, and a professional appearance. Internal M-Brace reinforcement increases structural rigidity and minimizes unwanted vibration, supporting cleaner sound at high volume. Lightweight yet durable, the enclosure is suited to portable systems, live stages, venues, and fixed installations.
Sleek, Professional Look
A professional appearance of an ART 8 speaker is ideal for live events or installed applications. The sleek black cabinet uses a special polypropylene composite material with a radically new construction concept. The grille cover is heavy-duty steel, protecting both transducers and vented ports.
Specs:
Speaker Type
Active Loudspeaker
Configuration
2-Way
Total Output Power
1400 W
LF Driver
1x 10" / 25.4 cm Woofer
Voice Coil: 2.5" / 63.5 mm
HF Driver
1x 1" / 25.4 mm Titanium Compression Driver
Voice Coil: 1.75" / 44.45 mm
Frequency Range/Response
50 Hz to 20 kHz
Speaker Type
Active Loudspeaker
Configuration
2-Way
Enclosure Type
Bass-Reflex
Total Output Power
1400 W
Amplifier Power Rating
Low Frequency (LF)
1000 W Peak
Mid Frequency (MF)
400 W Peak
Amplifier Class
Class-D
Drivers
LF Driver
1x 10" / 25.4 cm Woofer
Voice Coil: 2.5" / 63.5 mm
HF Driver
1x 1" / 25.4 mm Titanium Compression Driver
Voice Coil: 1.75" / 44.45 mm
Performance
Frequency Range/Response
50 Hz to 20 kHz
Maximum SPL
129 dB (Peak)
Coverage Angle
100° H x 60° V
Protections
RMS, Signal Limiter, Thermal
Signal Processing
Crossover Frequency
1600 Hz
EQ & Filters
No
Dynamic Processing
Soft Limiter
Alignment Delay
No
Digital Signal Processing
FIR Filter, Venue Settings
Connectivity
Audio I/O
1x Combo XLR-1/4" TRS Input
1x XLR 3-Pin Thru/Output
Network I/O
No
USB I/O
No
Wireless
No
Mobile App Compatible
No
Power
AC Input Power
100 to 120 VAC, 60 Hz
AC Power I/O
1x IEC Input
Physical
Color
Black
Mounting
Stand Mount
1 x 1.38" / 35 mm Pole Socket (Bottom)
Suspension Points
1 x M10 Fly Point (Top)
1 x M10 Fly Point (Bottom)
Handles
1x Top
Construction Material
Composite, Stainless Steel Grille
Environmental Resistance
No
Dimensions
22.3 x 13 x 12.2" / 566.4 x 330.2 x 309.9 mm
Weight
35.3 lb / 16 kg
