RCF ART-812A

RCF ART-812A

MSRP: $1,019.00
MAP: $699.00

Active 1400W 2-Way 12" Speaker

SKU: RCF-ART-812A

Only Approved Dealers can purchase.
Please Sign In.

or Become A Dealer to gain access today.

Overview

ART 812-A is a portable two-way active speaker built for DJs, musicians, and installers who want professional sound, robust performance, and everyday versatility in a sleek, modern form factor. A 1.75" compression driver, 12" woofer, and powerful 1400 W two-channel amplifier work with RCF’s constant-directivity True Resistive Waveguide to deliver consistent 100° x 60° coverage, clear reproduction, and up to 129 dB SPL with low distortion. The lightweight yet rugged cabinet uses a special polypropylene composite with internal M-brace reinforcement for improved stability and reduced resonance, making ART 812-A fast to deploy, easy to handle, and ready for portable systems or secure installation on a pole, wall, truss, or flown setup via multiple rigging points.

Features
  • 129 dB Max SPL
  • 1400 W Class D Bi-Amplification
  • 100° x 60°, Wide dispersion True Resistive Waveguide
  • XBOOST Low-Frequency Enhancer
  • 1.75" Compression Driver
  • 12" Woofer
  • FiRPHASE and BMC processing

Specifications

ACOUSTICAL
  • Frequency Response: 50 Hz - 20000 Hz
  • Max SPL @ 1m: 129 dB
  • Horizontal coverage angle: 100°
  • Vertical coverage angle: 60°
TRANSDUCERS
  • Compression Driver: 1 x 1.0'', 1.75'' v.c
  • Woofer: 1 x 12'', 2.5'' v.c
INPUT/OUTPUT SECTION
  • Input signal: bal/unbal
  • Input connectors: XLR, Jack
  • Output connectors: XLR
  • Input sensitivity: -2 dBu/+4 dBu
  • Mic. Input Sensitivity: -32 dBu
PROCESSOR SECTION
  • Crossover Frequencies: 1600
  • Protections: Thermal, RMS
  • Limiter: Soft Limiter
  • Controls: Volume, Boost, MIC/Line
POWER SECTION
  • Total Power: 1400 W Peak
  • High frequencies: 400 W Peak
  • Low frequencies: 1000 W Peak
  • Cooling: Convection
  • Connections: VDE
STANDARD COMPLIANCE
  • Safety agency: CE compliant
PHYSICAL
  • Cabinet/Case Material: PP Composite
  • Hardware: 3 x M10, 1 on top e 1 each side
  • Handles: 1 on top, 1 each side
  • Pole mount/Cap: 35 mm insert
  • Grille: Steel
  • Color: Black
SIZE / WEIGHT
  • Height: 634.9 mm / 25 inches
  • Width: 369.9 mm / 14.56 inches
  • Depth: 363.2 mm / 14.3 inches
  • Weight: 19 kg / 41.89 lbs
SHIPPING INFORMATION
  • Package Height: 685 mm / 26.97 inches
  • Package Width: 430 mm / 16.93 inches
  • Package Depth: 423 mm / 16.65 inches
  • Package Weight: 21.2 kg / 46.74 lbs
