Features
- Used to add transformer isolation to any line-level RDL product input
- Frequency response: 20 Hz to 20 kHz (+/- 0.5 dB)
- THD: < 0.05% (1 kHz)
- 10 kΩ input bridges any audio line
- Balanced input and output
- Connections on Detachable Terminal Blocks
Specifications
| Ambient Operating Environment | 0° C to 55° C |
| Package Type | Cardboard Box |
| Package Dimensions | 2 x 2 x 4 in. |
| Shipping Weight | 0.31 lbs. |
| WEEE weight | 0.255 lbs. |
| Tariff code | 8518.29.0000 |
