Overview:
The Vivitek DK5153Z-WH is a professional 4K UHD laser projector designed for conference rooms, higher education, corporate environments, simulation applications, and professional AV installations. Delivering up to 6,500 lumens of brightness, it features built-in edge blending and warping, 21:9 ultrawide support, HDR10 compatibility, HDBaseT expansion capability, and flexible installation tools including lens shift, keystone correction, and 360° projection support.
Features:
4K UHD resolution
6,200-lumen brightness
Laser phosphor light source
HDR10 support
21:9 ultrawide display support
Built-in edge blending
Built-in warping capability
360-degree projection support
Portrait mode installation
24/7 operation capability
PJ-Control management software
Optional HDBaseT expansion
IP6X dust-protected optical engine
Keystone and 4-corner correction
Suitable for simulation and immersive AV environments
Specs:
| Product Type | 4K UHD Laser Projector |
| Projection Technology | DLP |
| Native Resolution | 3840 x 2160 (4K UHD) |
| Brightness | 6,200 Lumens |
| Contrast Ratio | 3,000,000:1 |
| Light Source | Laser Phosphor |
| Light Source Life | 20,000 Hours (Normal) / 30,000 Hours (Eco) |
| Aspect Ratio | 16:9 |
| 21:9 Support | Yes |
| Throw Ratio | 1.15:1 - 1.90:1 |
| Zoom | 1.65x Manual |
| Lens Shift (Horizontal) | ±2% |
| Lens Shift (Vertical) | +22% / -2% |
| HDMI Inputs | 2 x HDMI 2.0 |
| Network Control | RJ45 LAN |
| Operation | 24/7 Continuous |
| Projection Orientation | 360° and Portrait Mode |
| Built-In Speaker | 10W Mono |
| Power Requirement | 100-240V AC, 50/60Hz |
| Power Consumption | 565W |
| Product Weight | 26.4 lb |
| Product Dimensions | 19.5 x 14.9 x 6.3 in |
