| CONSTRUCTION & DIMENSIONS | - |
| CONDUCTOR PARAMETER | - |
| Number of Conductors | 1 |
| AWG Size | 20 |
| Conductor Stranding | Solid |
| Conductor Type | Bare Copper |
| Nominal DCR | 10.1 Ohm/1000ft |
| INSULATION PARAMETER | - |
| Insulation Type | Foam FEP |
| Insulation Thickness | 0.135 in |
| SHIELDING PARAMETER | - |
| Shield Type | Overall 100% Aluminum Foil |
| Shield Type 2 | 95% Tinned Copper Braid |
| ELECTRICAL CHARACTERISTICS | - |
| Nominal Impedance | 75 Ohm |
| Nom. Cap. Between Conductors | 16.2 pF/ft |
| OVERALL CONSTRUCTION PARAMETERS | - |
| Jacket Type | Flexible Plenum |
| Nominal Cable O.D. | 0.2 in |
| Plenum | Yes |
| NEC UL Rating | CMP |
| RoHS Compliant | Yes |
| Pull Tension | 55 lbs |
| Bend Radius | 2 in |
| Cable Weight | 35 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | - |
| Nominal Velocity of Propagation (VP) | 82 % |
| UL Flammability | NFPA 262 Plenum |
| Operating Range | -0 to 60 Deg C |
| UL Voltage Rating | 300 |
| FREQUENCY (MHz) | ATTENUATION (db/100ft) |
| 1 MHz | 0.28 dB |
| 3.6 MHz | 0.48 dB |
| 10 MHz | 1.03 dB |
| 71.5 MHz | 2.2 dB |
| 135 MHz | 2.83 dB |
| 270 MHz | 4.55 dB |
| 360 MHz | 5.24 dB |
| 540 MHz | 6.12 dB |
| 720 MHz | 7.29 dB |
| 1000 MHz | 9.4 dB |
| 2250 MHz | 17.48 dB |
| 3000 MHz | 21.6 dB |
