| CONSTRUCTION & DIMENSIONS | |
| CONDUCTOR PARAMETER | |
| Conductor Type | Optical Fiber |
| Number Of Fibers | 4 |
| Fiber Optic Size | 50 |
| OM Fiber Optic Rating | OM3 |
| INSULATION PARAMETER | |
| Insulation Type | Plenum Thermoplastic |
| Buffer Size | 900 m |
| Insulation Color Code | 1.Blue,2.Orange,3.Green,4.Brown |
| SHIELDING PARAMETER | |
| Fiber Optic Design | Breakout |
| ELECTRICAL CHARACTERISTICS |
| OVERALL CONSTRUCTION PARAMETERS | |
| Jacket Type | Plenum PVC |
| Nominal Cable O.D. | 0.3 in |
| Plenum | No |
| NEC UL Rating | OFNP |
| RoHS Compliant | Yes |
| TIA Test | ANSI/TIA-568-C.3 |
| Pull Tension | 300 lbs |
| Bend Radius | 3 in |
| Cable Weight | 21 lbs |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | |
| UL Flammability | NFPA62 |
| CSA Flammability | FT4 |
| Operating Range | -40 to 70 Deg C |
| Operating Wavelength | 850/1300 |
| Min. OFL Bandwidth | 1500/500 |
| Max. Attenuation | 3.50/1.25 |
