| CONDUCTOR PARAMETERS | |
| Conductor Type | Optical Fiber |
| Number Of Fibers | 12 |
| Fiber Optic Size | 8.3/125 |
| OM Fiber Optic Rating | Single Mode |
| INSULATION PARAMETERS | |
| Insulation Type | UV Resistant Thermoplastic |
| Buffer Size | 900 µm |
| Insulation Color Code | 1.Blue,2.Orange,3.Green,4.Brown,5.Slate,6.White,7.Red,8.Black,9.Yellow,10.Violet,11.Rose,12.Aqua |
| SHIELDING PARAMETERS | |
| Fiber Optic Design | Distribution |
| ELECTRICAL CHARACTERISTICS |
| OVERALL CONSTRUCTION | |
| Jacket Type | UV Resistant Polyolein |
| Nominal Cable O.D. | 0.225 in |
| Plenum | Yes |
| NEC UL Rating | OFNP |
| RoHS Compliant | Yes |
| TIA Test | TIA455-82 Water Penetration Test, ANSI/TIA-568-C.3 |
| Pull Tension | 300 lbs |
| Bend Radius | 2.25 in |
| Cable Weight | 22 lbs |
| Indoor/Outdoor OFNP | Yes |
| OVERALL ELECTRICAL/OPTICAL CHARACTERISTICS | |
| UL Flammability | NFPA 262 Plenum |
| CSA Flammability | FT6 |
| Operating Range | -40 to 70 Deg C |
| Operating Wavelength | 1310/1550 |
| Min. OFL Bandwidth | Unlimited |
| Max. Attenuation | .80/.50 |
